Wall Mounted 10.1 Inch All In One Tablet PC With Android 11 OS WIFI POE JR45 Port

Brand Name : SAEF

Model Number : X101T-3566

Certification : ISO9001 / ISO14000

Place of Origin : ShenZhen / China

MOQ : 2 pcs

Price : Negotiable based on order quantity

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 3000K pcs per month

Delivery Time : 1-5 weeks

Packaging Details : Standard Exportation Package

Product : 10.1 inch All In One Tablet PC

Resolution : 1280x800 dots

Brightness : 300 cdm2

Display area : 215×135mm (16:10)

CPU : RK3566

RAM : 2GB

ROM : 16GB

System : Android 11/13OS

WIFI : 802.11b/g/n

Multi-Media : Video/Audio/Picture

Speaker : 2×2W speakers

Camera : Standard 200W pixel camera

Adapter : One, 12V/2A

POE : Yes

Contact Now

X101T - 3566: 10 inch wall mounted Android multi touch advertising display screen, excellent performance leading commercial display

10 inch Android multi touch advertising display with a resolution of 1280x800 is an ideal choice for commercial display and public information dissemination. The features of this monitor are as follows:

  • Display screen: 10 inch TFT LCD screen with a resolution of 1280x800 pixels ensures clear and delicate images.
  • Multi touch: Supports multi touch functionality, making user interaction more intuitive and flexible.
  • Operating System: Built in Android operating system, users can install and run various applications as needed.
  • VESA compatible: Following the VESA standard, it has 75x75 mm mounting holes for easy installation on various VESA compatible wall brackets.

  • POE function: Supports Power over Ethernet (POE), transmitting data and power through a single Ethernet cable, simplifying wiring requirements.

  • RJ45 port: Provides RJ45 Ethernet interface, supports wired network connection, and ensures stable data transmission.

  • Wall mounted installation: Designed for wall mounted installation, suitable for displaying advertisements or information in shopping malls, hotels, offices, and other places.

  • Application scenarios: Suitable for various commercial environments such as digital signage, advertising playback, information announcements, interactive applications, etc.

  • Durability: Adopting industrial grade design to ensure stable operation in various environments.

  • Scalability: Provides multiple interfaces, such as USB, HDMI, etc., for easy connection to external devices.


This Android multi touch advertising display monitor provides users with a multifunctional commercial display solution with its high-definition display, multi touch, and powerful network capabilities.


Features

Display Screen 10.1 inch IPS screen
Resolution 1280×800
Brightness 300 cdm2
Contrast 800:01:00
Screen scale/Display area 16:10/ Display area : 213.39×132.66mm
Configuration CPU Rockchip RK3566
RAM 2GB
ROM 16GB
System Android 11/13
Network WIFI 802.11b/g/n
Ethernet Supports connection to the RJ45 network interface
Bluetooth Bluetooth 4.0
3G/4G Support external 3G/4G USB dongle
Jack SD 1×SD card slots (max support 32GB)
Mini USB 1×USB OTG (through it to debug the machine, brush the system program)
USB 2.0 3×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 1×RJ45 network interface
POE 1×POE interface
Earphone 1×3.5mm headphone jack
Power 1×4.0mm power DC jack
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG,JPG
Other parameters Wireless mouse keyboard Support
Speaker 2×2W speakers
Camera Standard 200W pixel camera (500W pixel camera optional)
OSD language Chinese, English, German, Korean, Russian, French, Spanish, Arabia etc OSD operations
Software support Free installation applications (maps, games, e-mail, self developing apps, etc.)
Attachment US, EU, UK, AU Adapter One, specifications: 12V/2A
Desktop Bracket One
Wall mounted One
Remote control No
User's Manual One
Theftproof cover plate One, (can cover insert devices, such as U disk or SD card, to prevent theft)



Package

Body Size Color Box 10pcs/Carton
Length Width Thickness Length Width Height Length Width Height
245 170 25 385 225 60 470 400 320
N.W 0.64KG N.W 0.96KG N.W 9.6KG

Unit: mm


Mechanical Outline Drawing

Wall Mounted 10.1 Inch All In One Tablet PC With Android 11 OS WIFI POE JR45 Port
Product Image

Wall Mounted 10.1 Inch All In One Tablet PC With Android 11 OS WIFI POE JR45 Port
Wall Mounted 10.1 Inch All In One Tablet PC With Android 11 OS WIFI POE JR45 Port
Wall Mounted 10.1 Inch All In One Tablet PC With Android 11 OS WIFI POE JR45 Port
